Harley-Davidson FXDLI Dyna Low Rider - 2004 Specifications and Reviews

2004
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2004
Model:Harley-Davidson FXDLI Dyna Low Rider


Engine and Transmission Specifications

Transmission typefinal drive:Belt
Gearbox:5-speed
Cooling system:Air
Fuel control:DOHC
Valves per cylinder:2
Fuel system:Carburettor
Bore x stroke:95.3 x 101.6 mm (3.8 x 4.0 inches)
Compression:8.8:1
Torque:102.00
Stroke:4
Engine type:V2
Capacity:1449.00 ccm (88.42 cubic inches)

Physical measures and capacities

Wheelbase:1,595 mm (62.8 inches)
Ground clearance:116 mm (4.6 inches)
Overall width:673 mm (26.5 inches)
Overall length:2,340 mm (92.1 inches)
Seat height:640 mm (25.2 inches) If adjustable, lowest setting.
Dry weight:290.0 kg (639.3 pounds)

Harley-Davidson FXDLI Dyna Low Rider dimensions and frame

Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Single disc
Rear tyre dimensions:150/80-B16
Front tyre dimensions:100/90-19
Trail:130 mm (5.1 inches)
Rake (fork angle):32.0°

Speed and acceleration

Top speed:160.0 km/h (99.4 mph)

Other specs

Color options:Vivid black, brilliant silver, sierra red, impact blue, luxury blue, glacier white pearl, lava red sunglo, two-tone luxury blue and impact blue, two-tone sierra red and brilliant silver, two-tone smokey gold and vivid black
Fuel consumption pr. 10 km (6.2 miles):0.65 litres (0.17 gallons)
Fuel capacity:17.40 litres (4.60 gallons)
