Harley-Davidson FLSTC Heritage Softail Classic - 2010 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2010
Model:Harley-Davidson FLSTC Heritage Softail Classic

Engine and Transmission Specifications

Exhaust system:Chrome, staggered shorty exhaust with dual mufflers
Clutch:9-plate, wet
Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Air
Fuel system:Injection. Electronic Sequential Port Fuel Injection
Bore x stroke:95.3 x 111.1 mm (3.8 x 4.4 inches)
Compression:9.2:1
Torque:121.00 Nm (12.3 kgf-m or 89.2 ft.lbs) @ 3250
Engine type:V2, four-stroke
Capacity:1584.00 ccm (96.66 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes diameter:292 mm (11.5 inches)
Rear brakes:Single disc. 2-piston
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Single disc. 4-piston
Rear tyre dimensions:150/80-B16
Front tyre dimensions:MT90-B16
Rear suspension travel:109 mm (4.3 inches)
Rear suspension:Hidden, horizontal-mounted, coil-over
Front suspension travel:130 mm (5.1 inches)
Front suspension:41.3mm telescopic, beer can covers
Trail:147 mm (5.8 inches)
Rake (fork angle):31.0°
Frame type:Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded.

Physical measures and capacities

Oil capacity:3.10 litres (0.20 quarts)
Fuel capacity:19.70 litres (5.20 gallons)
Wheelbase:1,635 mm (64.4 inches)
Ground clearance:131 mm (5.2 inches)
Overall length:2,405 mm (94.7 inches)
Seat height:690 mm (27.2 inches) If adjustable, lowest setting.
Dry weight:326.0 kg (718.7 pounds)


Other specs

Color options:Vivid Black, Scarlet Red, Brilliant Silver Pearl, Flame Blue Pearl/ Brilliant Silver Pearl
