Harley-Davidson FLHXXX Street Glide Trike - 2011 Specifications and Reviews

2011
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2011
Model:Harley-Davidson FLHXXX Street Glide Trike

Engine and Transmission Specifications

Exhaust system:Two-into-One-into-Two chrome exhaust
Driveline:Primary Drive: Chain, 34/46 ratio. Final Drive: Belt, 30/70 ratio.
Clutch:Multi-plate, wet
Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Air
Lubrication system:Pressurized, dry-sump with oil cooler
Fuel control:DOHC
Fuel system:Injection. Electronic Sequential Port Fuel Injection
Bore x stroke:95.3 x 111.0 mm (3.8 x 4.4 inches)
Compression:9.6:1
Torque:137.00 Nm (14.0 kgf-m or 101.1 ft.lbs) @ 3500
Engine details:Twin Cam 103. Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters: two valves per cylinder.
Engine type:V2, four-stroke
Capacity:1687.97 ccm (103.00 cubic inches)


Brakes, suspension, Frame and wheels

Wheels:Black, 7-spoke Cast Aluminum
Rear brakes diameter:228 mm (9.0 inches)
Rear brakes:Double disc. ABS
Front brakes diameter:299 mm (11.8 inches)
Front brakes:Single disc. ABS
Rear tyre dimensions:205/65-R16
Front tyre dimensions:MT90-B16
Rear suspension travel:75 mm (3.0 inches)
Rear suspension:Air-adjustable shocks
Front suspension travel:117 mm (4.6 inches)
Front suspension:41.3 mm telescopic, triple-circuit damping
Trail:100 mm (3.9 inches)
Rake (fork angle):26.0°
Frame type:Mild steel, square-section backbone with twin downtubes

Physical measures and capacities

Oil capacity:3.70 litres (0.24 quarts)
Fuel capacity:22.71 litres (6.00 gallons)
Wheelbase:1,691 mm (66.6 inches)
Ground clearance:119 mm (4.7 inches)
Overall width:1,389 mm (54.7 inches)
Overall length:2,687 mm (105.8 inches)
Seat height:721 mm (28.4 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:503.0 kg (1,108.9 pounds)
Dry weight:485.0 kg (1,069.2 pounds)


Other specs

Carrying capacity:Front and rear rack
Wheelbase:1,490 mm (58.7 inches)
Overall height:1,230 mm (48.4 inches)
Power/weight ratio:0.1114 HP/kg
Rear tyre:25/10-12
Front tyre:25/8-12
Rear Suspension:Gas shocks with pre-load adjustment
Front Suspension:Independent double A-arm
Ignition:CDI
Bore x Stroke:96.0 x 82.0 mm (3.8 x 3.2 inches)
Compression:10.2:1
Torque:46.90 Nm (4.8 kgf-m or 34.6 ft.lbs)
Power:37.55 Horsepower">HP (27.4 Kilowatt">kW))
Capacity:594.00 ccm (36.25 cubic inches)
Model:Goes G 625i Max
Color options:Vivid Black, Cool Blue Pearl, Merlot Sunglo/Vivid Black, Cool Blue Pearl / Vivid Black
Factory warranty:24 months
Light:55-watt low beam, 60-watt high beam
Instruments:Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-spe
Starter:Electric
