Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Torque:
135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250
Compression:
9.6:1
Bore x stroke:
98.4 x 111.2 mm (3.9 x 4.4 inches)
Valves per cylinder:
2
Fuel system:
Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Fuel control:
OHV
Lubrication system:
Pressurized, dry-sump with oil cooler
Cooling system:
Air
Gearbox:
6-speed
Transmission type,final drive:
Belt
Clutch:
Multi-plate, wet
Driveline:
Chain, 34/46 ratio
Fuel consumption:
5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Greenhouse gases:
129.9 CO
Brakes, suspension, Frame and wheels
Frame type:
Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Rake (fork angle):
26.0°
Trail:
170 mm (6.7 inches)
Front suspension:
41.3 mm telescopic
Rear suspension:
Air-adjustable
Front tyre dimensions:
130/80-B17
Rear tyre dimensions:
180/65-B16
Front brakes:
Single disc. ABS
Front brakes diameter:
300 mm (11.8 inches)
Rear brakes:
Single disc. ABS
Rear brakes diameter:
300 mm (11.8 inches)
Physical measures and capacities
Dry weight:
367.0 kg (809.0 pounds)
Weight incl. oil, gas, etc:
380.1 kg (838.0 pounds)
Overall height:
1,450 mm (57.1 inches)
Overall length:
2,451 mm (96.5 inches)
Overall width:
970 mm (38.2 inches)
Ground clearance:
150 mm (5.9 inches)
Wheelbase:
1,626 mm (64.0 inches)
Fuel capacity:
22.71 litres (6.00 gallons)
Reserve fuel capacity:
3.79 litres (1.00 gallons)
Oil capacity:
3.80 litres (0.25 quarts)
Other specs
Starter:
Electric
Electrical:
Sealed, maintenance-free, 12V, 28-amp/hour, 270 cca (per Battery Council International Rating) battery.
Factory warranty:
24 months unlimited milage
Color options:
Red
Comments:
Bead-retention tires designed to remain on wheel during sudden loss of pressure; sealed, automotive-style wheel bearings requiring no end play adjustments and service interval of 100,000 miles (160,000 km).
