Harley-Davidson Dyna Fat Bob Dark Custom - 2014 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2014
ModelHarley-Davidson Dyna Fat Bob Dark Custom



Engine and Transmission Specifications

Exhaust systemChrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
Greenhouse gases129.9 CO
Fuel consumption5.60 litres/100 km (17.9 km/l or 42.00 mpg)
DrivelineChain, 34/46 ratio primar drive
ClutchMulti-plate with diaphragm spring in oil bath
Transmission type,final driveBelt
Gearbox6-speed
Cooling systemAir
Lubrication systemDry-sump
Fuel systemInjection. Electronic Sequential Port Fuel Injection
Bore x stroke98.4 x 111.3 mm (3.9 x 4.4 inches)
Compression9.6:1
Torque135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3500
Engine detailsAir-cooled, Twin Cam 103™
Engine typeV2, four-stroke
Capacity:1687.97 ccm (103.00 cubic inches)

Brakes, suspension, Frame and wheels

WheelsMachined, Aluminum Slotted Disc
Rear brakesSingle disc. 2-piston torque-free floating
Front brakesDouble disc. 4-piston fixed
Rear tyre dimensions180/70-B16
Front tyre dimensions130/90-B16
Trail124 mm (4.9 inches)
Rake (fork angle)29.0°



Physical measures and capacities

Oil capacity2.80 litres (0.18 quarts)
Fuel capacity18.93 litres (5.00 gallons)
Wheelbase1,621 mm (63.8 inches)
Ground clearance124 mm (4.9 inches)
Overall length2,329 mm (91.7 inches)
Seat height663 mm (26.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc320.2 kg (706.0 pounds)

Other specs

CommentsLithium Iron Phosphate 48V/20Ah battery, 16.8 kg. Range 60 km. Recharging time: 4 hours. Made in Taiwan.
Overall width625 mm (24.6 inches)
Overall height1,005 mm (39.6 inches)
Power/weight ratio0.0383 HP/kg
Dry weight56.2 kg (123.9 pounds)
Rear tyre80/100-10
Front tyre80/100-10
Rear SuspensionSingle Hydraulic Shock Absorber
Front SuspensionDual Hydraulic Shock Absorber
Frame typeSteel tube
Emission detailsZero emission
Top speed45.0 km/h (28.0 mph)
Power2.15 Horsepower">HP (1.6 Kilowatt">kW))
ModelGreenTrans EM80
Color optionsBlack Deni, Vivid black, Sand camo denim, Amber wiskey
LightHigh beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system(optional), 6-speed, low fuel warnings
InstrumentsTank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
StarterElectric
