Derbi Senda DRD Pro 50 R - 2011 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

Engine and Transmission Specifications

ClutchMultiplate
Transmission type,final driveChain
Gearbox6-speed
Cooling systemLiquid
Lubrication systemOil pump
Fuel controlSOHC
Fuel systemCarburettor. 17.5 mm
Bore x stroke39.9 x 40.0 mm (1.6 x 1.6 inches)
Compression11.5:1
Engine typeSingle cylinder, two-stroke
Capacity:49.90 ccm (3.04 cubic inches)



CategoryEnduro / offroad
Year2011
ModelDerbi Senda DRD Pro 50 R

Brakes, suspension, Frame and wheels

Rear brakes diameter220 mm (8.7 inches)
Rear brakesSingle disc
Front brakes diameter260 mm (10.2 inches)
Front brakesSingle disc
Rear tyre dimensions110/80-18
Front tyre dimensions90/90-21
Rear suspension travel250 mm (9.8 inches)
Rear suspensionProgressive linkage monoshock with separate gas tank.
Front suspension travel250 mm (9.8 inches)
Front suspension40 mm Upside down fork.



Physical measures and capacities

Oil capacity1.20 litres (0.08 quarts)
Reserve fuel capacity1.60 litres (0.42 gallons)
Fuel capacity6.50 litres (1.72 gallons)
Wheelbase1,390 mm (54.7 inches)
Overall width808 mm (31.8 inches)
Overall length2,080 mm (81.9 inches)
Overall height1,196 mm (47.1 inches)
Seat height920 mm (36.2 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc104.0 kg (229.3 pounds)
Dry weight96.0 kg (211.6 pounds)

Other specs

CommentsAlso available in a long version.
InstrumentsDigital
Wheelbase1,290 mm (50.8 inches)
Ground clearance275 mm (10.8 inches)
Power/weight ratio0.1014 HP/kg
WheelsOthers
Rear tyre270/60-12
Front tyre188/85-12
Rear SuspensionDouble wishbone Independent Suspension, Coil Spring Oil Damp Shock Absorber
Front SuspensionDouble wishbone Independent Suspension, Coil Spring Oil Damp Shock Absorber
Driveline2 Wheel Drive and 4 wheel Drive switch
IgnitionECU
Valves per cylinder4
Bore x Stroke87.5 x 82.0 mm (3.4 x 3.2 inches)
Compression10.2:1
Torque45.10 Nm (4.6 kgf-m or 33.3 ft.lbs) @ 4832 Revolutions">RPM
Power34.87 Horsepower">HP (25.5 Kilowatt">kW)) @ 6389 Revolutions">RPM
Capacity:493.00 ccm (30.08 cubic inches)
ModelCF Moto X-lander X5
Color optionsRed/white
ElectricalBattery 12V 4Ah
StarterElectric
