BMW R 1200 GS - 2004 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Allround
Year:2004
Model:BMW R 1200 GS

Engine and Transmission Specifications

Transmission typefinal drive:Shaft drive (cardan)
Gearbox:5-speed
Cooling system:Oil & air
Fuel control:SOHC
Valves per cylinder:4
Fuel system:Injection
Bore x stroke:101.0 x 73.0 mm (4.0 x 2.9 inches)
Compression:10.0:1
Torque:115.00
Power:98.00
Stroke:4
Engine type:Two cylinder boxer
Capacity:1170.00 ccm (71.39 cubic inches)


Physical measures and capacities

Wheelbase:1,641 mm (64.6 inches)
Overall width:915 mm (36.0 inches)
Overall length:2,210 mm (87.0 inches)
Overall height:1,430 mm (56.3 inches)
Alternate seat height:860 mm (33.9 inches) If adjustable, highest setting.
Seat height:840 mm (33.1 inches) If adjustable, lowest setting.
Dry weight:199.0 kg (438.7 pounds)


BMW R 1200 GS dimensions and frame

Rear brakes diameter:265 mm (10.4 inches)
Rear brakes:Single disc
Front brakes diameter:305 mm (12.0 inches)
Front brakes:Double disc
Rear tyre dimensions:150/70-ZR17
Front tyre dimensions:110/80-ZR19
Rear suspension travel:200 mm (7.9 inches)
Rear suspension:Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable
Front suspension travel:190 mm (7.5 inches)
Front suspension:BMW Motorrad Telelever;stanchion diameter 41 mm, central spring strut, spring pre-load 9-times mechanically adjustable
Frame type:Three-section composite frame consisting of front and rear section, load bearing engine.

Speed and acceleration

Power/weight ratio:0.4925 HP/kg
Top speed:200.0 km/h (124.3 mph)

Other specs

Fuel consumption pr. 10 km (6.2 miles):4.50 litres (1.19 gallons)
Reserve fuel capacity:4.00 litres (1.06 gallons)
Fuel capacity:20.00 litres (5.28 gallons)
